7
SMART 7KT0210 Manual
Assembly
Installation
For installing the meter
Prepare the panel cutout with proper dimensions as shown below.
FRONT PANEL DESCRIPTION
OUTLINE
Dimensions (in mm)
PANEL CUTOUT
Dimensions (in mm)
