Siemens 7XR61 Series User Manual

English 7XR6100-0*A00
12 C53000-B119U-C124-1
General Diagram
Figure 5 General diagram 7XR6100-0*A00
Surface mounting case / Flush mounting case
with 230 V AC between 1A1 and 1A4
with 100 to 125 V AC between 1A1 and 1A3
230 V AC
100 bis 125 V AC
58 to 74 V AC
1)
64 V AC
2)
39 to 49 V AC
1)
43 V AC
2)
