7XR6100-0*A00 English
C53000-B119U-C124-1 11
Limit values of inputs and outputs
Auxiliary voltage
Load capability of the capacitive coupling circuit
Connections (4A1 - 4B1)
Permissible voltage, continuous 3.15 kV dc
R.M.S. value of voltage 220 V~ (≤ 50 Hz)
R.M.S. value of current ≤ 0.2 A *) continuously
Test voltage 4.7 kV dc for ≤ 2s
Output ratings
(Short circuit on 4A1 and 4B1)
Continuous 100 mA (without choke)
Output (1B1 - 1B3) 175 mA (with choke) max. 1 h
Output (1B1 - 1B4) 230 mA max. 0.5 h
*) Don't use the internal resistors in case of higher currents. In the event of a large harmonics
content in the rotor voltage an external series resistor, type 3PP1336-0DZ-013002 is
recommended for the protection of the coupling capacitors (refer connection example 2).
Rated auxiliary voltage U
H
ac
100 to 125 V ac, 50/60 Hz 230 V ac, 50/60 Hz
Permissible variations ac
80 to 144 V ac 176 to 265 V ac
