English 7XV5655-0BA00
47 / 53 C53000-G1176-C174-3
- Relay output common mode; 2 KV; 42 Ù; 0.5 µF
differential mode : 1 KV; 42 Ω; 0.5 µF
Conducted RF, amplitude-modulated
IEC61000-4-6, Class III
10 V; 150 KHz – 80 MHz; 80 % AM, 1 KHz
Magnetic field with power
frequency
EN61000-4-8
IEC60255-6
0.5 mT; 50 Hz
Class IV: 30 A/m continuous; 300 A/m for 3s; 50Hz
Oscillatory Surge Withstand Capability
IEEE Std C37.90.1
2.5 KV (peak); 1 MHz;ז = 15 µs; 400 surges per s;
test duration 2s; Ri = 200 Ω
Fast transient surge withstand capability
IEEE Std C37.90.1
4 kV; 5/50 ns; 5 kHz; burst length = 15 ms;
Repeat rate 300 ms; pos./neg. polarity;
test duration 1 min.; Ri = 50 Ù
Damped oscillations
IEC 60694, IEC 61000-4-12
2.5 kV (peak value), polarity alternating 100 kHz,
1 MHz, Ri = 200 Ω
EMC tests for emission (type tests)
Standard:
EN 61000-6-4/3 (generic standard)
Radio interference voltage on lines
Auxiliary voltage only
IEC CISPR 22
150 kHz to 30 MHz
Limit class B
Interference field strength
IEC CISPR 11
30 to 1000 MHz
Limit value class A
Mechanical tests, vibration and shock
stress - stationary use
Vibration
IEC 60255-21-1, Class 2
IEC 60068-2-6
Sinusoidal, 10 to 58 Hz : 0.075 mm ampl.
58 to 150 Hz : 1.0 g accel.
20 cycles in 3 orthogonal axes
Shock
IEC 60255-21-2, Class 1
Semi-sinusoidal, 5 g accel., 11 ms duration
3 shocks each in both directions of the 3 axes
Seismic vibration
IEC 60255-21-3, Class 1
IEC 60068-3-3
Sinusoidal, 1 to 8 Hz : 4 mm ampl. horizontal
1 to 8 Hz : 2 mm ampl. vertical
8 to 35 Hz : 1 g accel., horizontal
8 to 35 Hz : 0.5 g accel., vertical
1 cycle in 3 orthogonal axes
