English 7XV5655-0BA00
48 / 53 C53000-G1176-C174-3
Mechanical tests, vibration and shock
stress - during transport
Vibration
IEC 60255-21-1, Class 2
IEC 60068-2-6
Sinusoidal, 5 to 8 Hz : 7.5 mm ampl.
8 to 150 Hz : 2 g accel.,
20 cycles in 3 orthogonal axes
Shock
IEC 60255-21-2, Class 1
IEC 60068-2-27
Semi-sinusoidal, 15 g accel., 11 ms duration
3 shocks each in both directions of the 3 axes
Shock
IEC 60255-21-2, Class 1
IEC 60068-2-27
Semi-sinusoidal, 10 g accel., 16 ms duration
1000 shocks each in both directions of the 3 axes
Climatic tests
Recommended operating temperature
Limit temp. during operation
Limit temp. during storage
Limit temp. during transport
Humidity
Maximum relative humidity
Installation altitude
Maximum height above sea level
0 °C to 55 °C
-5 °C to +70 °C
-25 °C to +55 °C (factory packing)
-25 °C to +70 °C (factory packing)
80 % at temperatures up to 31 °C,
decreasing linearly down to 50 % at 40 °C
2,000 m
All devices shall be installed so that they are not exposed to direct sunlight, nor subject to great
fluctuations in temperature that may cause condensation.
