Siemens LV 10 · 2004
7/34
Fuses and Fuse Systems
NEOZED fuses
* This quantity or a multiple thereof can be ordered.
7
■
Selection and ordering data
Version Size For fuses
up to
Identifi-
cation
color
DT
Order No. PS* Weight per
PU
approx.
A
kg
Mounting components for MINIZED DO2 switch disconnectors
Guide piece 20 blue A 5SH5 521 50 units 0.001
For non-interchangeable mounting of NEOZED
DO2 fuse links
25 yellow A
5SH5 522 50 units 0.001
35 black A
5SH5 523 50 units 0.001
50 white A
5SH5 524 50 units 0.001
Adapter A
5SH5 520 20 units 0.020
For adapting D01/D02
Mounting components for NEOZED fuses
NEOZED gauge pieces
D01 2 pink A 5SH5 002 50 units 0.001
4brownA
5SH5 004 50 units 0.001
6greenA
5SH5 006 50 units 0.001
10 red A
5SH5 010 50 units 0.001
D02 20 blue A
5SH5 020 50 units 0.001
25 yellow A
5SH5 025 50 units 0.001
35 black A
5SH5 035 50 units 0.001
50 white A
5SH5 050 50 units 0.001
For adapting NEOZED DO1 fuse links from 2 A ... 16 A for use in NEOZED DO2
sockets
D02 2 pink A 5SH5 402
50 units
0.001
4brownA
5SH5 404 50 units 0.001
6greenA
5SH5 406 50 units 0.001
10 red A
5SH5 410 50 units 0.001
16 gray A
5SH5 416 50 units 0.001
Mounting components for NEOZED retaining spring
For adapting NEOZED DO2 screw caps to adapt NEOZED DO1 fuse
links
D02 2 ... 16 A 5SH5 400 25 units 0.001
NEOZED guide piece keys
to DIN VDE 0680 A
5SH5 100 1 unit 0.016
Size Length Conductor
cross-section
Load rating
up to
For
terminals
MW DT Order No. PS* Weight per
PU
approx.
approx. mm mm
2
A kg
Busbars
Spade terminals, not insulated
Single-phase
D01 1000 20 116 R, K 1.5 A 5SH5 321 50 units 0.214
D02 1000 36 168 R, K 1.5 A
5SH5 322 50 units 0.321
Spade terminals, insulated
Single-phase
D01/D02 1000 24 160 R, FR2, K 1.5 A 5SH5 517 50 units 0.550
3-phase
D01/D02 1000 16 120 R, K 1.5 A 5SH5 320 20 units 0.843
D01/D02 1000 16 120 FR2, K 1.5 A
5SH5 515 10 units 0.584
Male contacts, insulated
Single-phase
D01/D02 1000 16 130 S 1.5 A 5SH5 324 50 units 0.320
3-phase
D01/D02 1000 16 120 S 1.5 A 5SH5 323 20 units 0.843
D01 1000 16 120 FR1 1 A
5SH5 512 15 units 0.630
D01 216 16 120 FR2, K 1.5 A
5U2 204 25 units 0.090
