Siemens LV 10 · 2004
7/44
Fuses and Fuse Systems
LV HRC fuses
* This quantity or a multiple thereof can be ordered.
7
■ Selection and ordering data
Characteristics are available on the Internet at
www.siemens.de/installationstechnik
Size Rated current I
n
Rated voltage U
N
DT Non-insulated grip
lugs
PS* Weight per
PU
approx.
Order No.
AV
kg
LV HRC fuses
Operational class gG, for cable and line protection
000 2 AC 500 V, DC 250 V A 3NA3 802 9 units 0.133
21 mm 4 A
3NA3 804 9 units 0.133
6A
3NA3 801 9 units 0.133
10 A
3NA3 803 9 units 0.133
16 A
3NA3 805 9 units 0.133
20 A
3NA3 807 9 units 0.133
25 A
3NA3 810 9 units 0.133
32 A
3NA3 812 9 units 0.133
35 A
3NA3 814 9 units 0.133
40 A
3NA3 817 9 units 0.133
50 A
3NA3 820 9 units 0.133
63 A
3NA3 822 9 units 0.133
80 A
3NA3 824 9 units 0.133
100 A
3NA3 830 9 units 0.133
00 35 AC 500 V, DC 250 V A
3NA3 814-7 3 units 0.200
30 mm 50 A
3NA3 820-7 3 units 0.200
63 A
3NA3 822-7 3 units 0.200
80 A
3NA3 824-7 3 units 0.200
100 A
3NA3 830-7 3 units 0.200
125 A
3NA3 832 3 units 0.217
160 A
3NA3 836 3 units 0.217
0 6 AC 500 V, DC 440 V A
3NA3 001 3 units 0.340
30 mm 10 A
3NA3 003 3 units 0.340
16 A
3NA3 005 3 units 0.340
20 A
3NA3 007 3 units 0.340
25 A
3NA3 010 3 units 0.340
32 A
3NA3 012 3 units 0.340
35 A
3NA3 014 3 units 0.340
40 A
3NA3 017 3 units 0.340
50 A
3NA3 020 3 units 0.340
63 A
3NA3 022 3 units 0.340
80 A
3NA3 024 3 units 0.340
100 A
3NA3 030 3 units 0.340
125 A
3NA3 032 3 units 0.340
160 A
3NA3 036 3 units 0.340
1 16 AC 500 V, DC 440 V A
3NA3 105 3 units 0.290
30 mm 20 A
3NA3 107 3 units 0.290
25 A
3NA3 110 3 units 0.290
35 A
3NA3 114 3 units 0.300
40 A
3NA3 117 3 units 0.300
50 A
3NA3 120 3 units 0.300
63 A
3NA3 122 3 units 0.300
80 A
3NA3 124 3 units 0.300
100 A
3NA3 130 3 units 0.300
125 A
3NA3 132 3 units 0.300
160 A
3NA3 136 3 units 0.300
47.2 mm 200 A
3NA3 140 3 units 0.440
224 A
3NA3 142 3 units 0.440
250 A
3NA3 144 3 units 0.440
