5 Technical Specifications
The technical data for the ACC-AP is as below:
Default IP Address
192.168.251.1
Subnet mask:
255.255.255.0
Supply voltage (nom.*)
12-24 Vnom +/- 10% 1Vpp ripple
Absolute voltage ratings**
9.5V DC – 29.5V DC
The AP power supply input must be
protected by a fuse (2A).
Current consumption
Without reader
Idle
12V DC: 200mA
24V DC: 140 mA
Full on***
12V DC: 600mA
24V DC: 400 mA
Battery Type
CR2032
Reader Interface
An electronic fuse blows when the total
current to both the reader interfaces
exceeds 700mA.
Two OSDP Readers plus Power out.
Two Wiegand Readers plus Power out.
Max 700mA (jumper in Vin position)
Max 200mA (jumper in 12V position)
Inputs
Four general inputs
Outputs
Two relay outputs. Max 30V DC, 2A. One
bistable, one monostable.
Four Open-collector outputs, max load 0.5A.
One power supply output with Vin, max load
2A.
Resistor Value for Monitored Inputs
22k (alarm)
11k normal
Temperature Range
-40 to +55
0
C
Humidity
25
0
C @80% -> 55
0
C @93%
(III, IEC 60839-11-1)
Environmental Class
II, IEC 60839-11-1
Dimensions (H x W x D)
156 x 201 x 53 mm
* Nominal voltage has margins for transformer tolerances, mains supply variations and
interruptions
** Absolute voltage has no margins and should be used for guidance only
*** Full on represents:
● 500 mA (5V) load on high-speed USB connector
● 100 mA (5V) load on full-speed USB connector
● No readers connected
● Relays activated
● RJ485 communication on all ports with EOL resistors
● Micro-SD memory card installed
