Sequoia Elastomer Replacement 5
Page 5 of 16
Medical Solutions USA, Inc.
2-
1Sequoia Elastomer Replacement
Overview 0
This document provides instructions for replacing the elastomer of a User Interface
Assembly on the ACUSON Sequoia ultrasound system.
Replacing the elastomer corrects the problem of sticky or unresponsive keys on the ultra-
sound UI keyboard.
Time Required 0
Elastomer replacement: approximately 1 hour
Tools Required 0
Tab. 1 Required tools to complete Sequoia Elastomer Replacement
Parts 0
User Interface Elastomer Repair Kit
Tab. 2 User Interface Elastomer Repair Kit
Tab. 3 User Interface Elastomer Repair Kit Contents
Description Qty
Standard CSE Toolkit 1
Kit Description Qty Part No.
Service Elastomer Repair Kit, Sequoia 1 08270240
Description Qty
L/R, U/D Elastomer 1
Main Elastomer 1
TEQ Elastomer 1
