2Installa tion and setti ngs
Work sequence 0
Installing the TCP/IP cable 0
• Plug the TCP/IP cross-over cable into the monitor trolley and into the 3D navigation
system (see figure below).
NOTE
If the ARCADIS system is connected to the navigation system via
the clinical network, there can be problems if the load on the clin-
ical network is heavy.
Fig. 3: Plug
Attaching the HW interface to the image intensifier 0
Fig. 4: I.I._01
