InstallationPXL Conventional Fire Alarm Control Panel
17
STEP 7Install the PCM-1
The installation kit for the PCM-1 consists of the following items:
ITEM PART NUMBER QUANTITY
plastic bezels 195-293693 4
power/cable 555-194066 1
3-position terminal block cover 305-192323 1
9-position terminal block cover 305-387037 1
PCM-1 LED label 575-493753 1
3.9K, 1/4W, EOL resistors 140-820186 12
zone labels 575-194072 3
4-position terminal block 150-094071 6
#6 x 3/8 Phillips screws 906-220606 8
If Class A conversion modules are to be used, refer to the PZC-4D
Installation Instructions, P/N 315-094164, before continuing with the
PCM-1 installation.
Mounting the PCM-1:
1. Place the PCM-1 board on the PMK-1 mounting bracket with the
component side facing down and with the locating pins protrud-
ing through the bottom of the bracket, as shown in Figure 11.
2. Fasten the PCM-1 to the mounting bracket at the positions
marked A in Figure 11 using the screws provided.
3. Remove the backing from the PCM-1 LED label and place it on
the PCM-1 bezel (Refer to Figure 11).
4. a. Complete the zone label for the zone overlay with the
appropriate zone description (Refer to Figure 12).
For example:
Floor 1, East Wing
Floor 1, West Wing
Slip the label under the overlay so the information shows
through.
b. Fill in the terminal block label with the appropriate zone
information.
5. Place each bezel in the appropriate position on the PCM-1 board
(Refer to Figure 11). Be sure that the locating pin on each bezel
goes through the appropriate hole in the bracket. Fasten the
bezels to the mounting bracket at the positions marked B in
Figure 11, using the screws provided.
