PXL Conventional Fire Alarm Control Panel
Operation
36
OPERATION
The PXL annunciates the following modes:
Alarm
Supervisory
Trouble
Normal
Alarm
The PXL Display board lights the appropriate red zone alarm LED
and the general ALARM LED to indicate to the user that an Alarm
condition exists. The following screen is displayed on the PXL:
ALARM 1 OF 1:
LOCATION
ACKNOWLEDGE ALARMS>
NOTE: The PXL can record and display up to 5 zone alarms prior to reset.
Supervisory
A Supervisory alarm condition is indicated on the PXL by the lighted
SUPERVISORY LED and the appropriate zone LEDs. The following
screen is displayed on the PXL:
SUPV 1 OF 1:
LOCATION
ACKNOWLEDGE SUPV’S>
Trouble
A Trouble condition is displayed by a lighted TROUBLE LED along
with the appropriate LEDs corresponding to the zone in trouble. The
following screen is displayed on the PXL:
TROUBLE 1 OF 1:
LOCATION
ACKNOWLEDGE TRBL’S>
For a description of the system trouble messages, see Trouble
Messages, page 56.
Normal
The Normal Mode is the absence of any alarm, supervisory, or
trouble condition. The POWER LED is lit in Normal mode when the
system has AC power. The Alarm, Trouble, Supervisory, Audibles
Program
- Program
- Test
- Control
- History
