Siemens Connect X200 User Manual

4
Siemens
A6V11974867_en--_b
Smart Infrastructure
2021-08-30
Activity
LED / Interface
Color
Activity
Function
Service button
Long press, up to
20s (power off device
first)
Factory reset
All configuration data and installed apps are
deleted
If RUN LED is constantly green, factory
reset was successful
Short press
IP address 169.254.169.254 will be
assigned to LAN port for the duration of 15
min.
Product documentation
Related documents such as the environmental declarations, CE declarations, etc., can be
downloaded from the following Internet address:
https://siemens.com/bt/download
Notes
Safety
CAUTION
National safety regulations
Failure to comply with national safety regulations may result in personal injury and property
damage.
● Observe national provisions and comply with the appropriate safety regulations.
Mounting position and ambient temperature
The devices can be snapped onto standard rails or screwed onto a flat surface.
Plug-in screw terminals connect power and interfaces (except for Ethernet).
Ambient temperature -5...50 °C (23...122 °F)
Ambient temperature -5...45 °C (23...113 °F)
● Wall, horizontal
– From left to right
– From right to left
● Overhead
● Wall, vertically
– From top to bottom
– From bottom to top
● On a horizontal surface
CAUTION
Risk of overheating for failure to comply with ambient temperature
Burning and damage to the device
● Ensure sufficient ventilation to comply with the permissible ambient temperature within
the panel or installation box. The temperature must be at least 10 K (18° F) lower out-
side the installation box.
