Siemens CP 1242-7 GPRS V2 User Manual

Configuration and operation
4.9 STEP 7 configuration
CP 1242-7 GPRS V2
Operating Instructions, 10/2016, C79000-G8976-C311-02
67
Character set for data point names
When you create a data point, a preset name "DataPoint_n" is adopted. In the data point
table and in the "General" tab of the data point you can change the name of the data point.
When assigning names only ASCII characters from the band 0x20 ... 0x7e may be used with
the exceptions listed below.
The following characters are forbidden since they do not adhere to the syntax rules of TCSB
for OPC items:
Non-permitted characters: . ' [ ] / \ |
period, apostrophe, square brackets, slash, back slash, vertical line (pipe)
4.9.7.2
Datapoint types
During the configuration of the user data to be transferred by the CP, each data point is
assigned a protocol-specific data point type. The data point types supported by the CP along
with the compatible S7 data types are listed below. They are grouped according to format
(memory requirements).
As of the firmware version named in the preface along with STEP 7Basic V14, the CP
supports the following data point types and data types.
Supported data point types of the CP
Table 4- 1 Supported data point types and compatible S7 data types
Format (memory re-
quirements)
Data point type
S7 data types
Address area
Bit
Digital input
Bool
I, Q, M, DB
Digital output
Bool
Q, M, DB
Byte
Digital input
Byte, USInt
I, Q, M, DB
Digital output Byte, USInt Q, M, DB
Integer with sign (16 bits)
Analog input
Int
I, Q, M, DB
Analog output
Int
Q, M, DB
Counter (16 bits)
Counter input
Word, UInt
I, Q, M, DB
Integer with sign (32 bits)
Analog input
DInt
Q, M, DB
Analog output
DInt
Q, M, DB
Counter (32 bits)
Counter input
UDInt, DWord
I, Q, M, DB
Floating-point number
with sign (32 bits)
Analog input
Real
Q, M, DB
Analog output
Real
Q, M, DB
Floating-point number
with sign (64 bits)
Analog input
LReal
Q, M, DB
Analog output
LReal
Q, M, DB
Block of data
(1 .. 64 bytes)
Data
ARRAY
1)
DB
Data
ARRAY
1)
DB
1)
For the possible formats of the ARRAY data type, refer to the following section.
