Siemens CP 1542SP-1 User Manual

Technical specifications
CP 1542SP-1, CP 1542SP-1 IRC, CP 1543SP-1
110 Operating Instructions, 01/2017, C79000-G8976-C426-03
Technical specifications
• PCF Standard Cable GP, PCF
Trailing Cable, PCF Trailing Ca-
ble GP
• Max. 100 m
Electrical data
External power supply (X80), design Socket
Terminal block for socket
Two terminals with reverse polarity protec-
tion
2 x two terminal for single or redundant
power supply
Power supply (external)
• Type of voltage
• Permitted low limit
• Permitted high limit
• 24 VDC
• 19.2 V
• 28.8 V
Current consumption
• From 24 VDC (external)
• From backplane bus (3.3 V)
• 250 mA (typ.)
• 4 mA (typ.)
Maximum Inrush current
(Rated value)
12 A
Effective power loss
(typical)
6 W
Overvoltage category according to
IEC / EN 60664-1
Category I
Permitted ambient conditions
Ambient temperature During operation with the rack in-
stalled horizontally
0 .. + 60 °C
During operation with the rack in-
stalled vertically
0 .. + 50 °C
During storage
-40 .. +70 °C
During transportation
-40 .. +70 °C
Relative humidity
During operation
≤ 95 % at 25 °C, no condensation
Design, dimensions and weight
Module format
Compact module ET 200SP
Degree of protection
IP20
Weight
• Without bus adapter
• With bus adapter 2xRJ45
• 180 g
• 230 g
Dimensions (W x H x D)
60 x 117 x 74 mm
Installation options
DIN rail (35 mm)
Mean Time Between Failures (MTBF)
• At + 40 °C
• At + 60 °C
• 56.87 years
• 24.78 years
Product functions **
*
For details of the cable lengths see ET 200SP system manual, /2/ (Page 119).
**
You will find additional properties and performance data in the section Application and
functions (Page 11).
