1.4 Telecontrol communication of the CP 1542SP-1 IRC
CP 1542SP-1, CP 1542SP-1 IRC, CP 1543SP-1
Operating Instructions, 01/2017, C79000-G8976-C426-03
13
1.4
Telecontrol communication of the CP 1542SP-1 IRC
Telecontrol protocols
In addition to the communications services named above, the CP 1542SP-1 IRC supports
the following telecontrol protocols for communication with a master station:
●
TeleControl Basic
This is a proprietary protocol of Siemens for telecontrol applications. The IP-based
protocol is used to connect the CP to the application TCSB.
TCSB is installed on a PC in the master station, the telecontrol server. Via the OPC-DA or
OPC-UA server of TCSB, an OPC client can access the process data of the CP.
TCSb is supported as of the following version: V3.0 + SP3
For the TCSB manual, see /3/ (Page 120).
●
DNP3
The CP functions as a DNP3 station (Outstation).
Communication is based on the DNP3 SPECIFICATION Version 2.11 (2007/2009).
You will find a detailed overview of the attributes and properties specified in the DNP3
protocol and supported by the CP in the DNP3 device profile, see Link:
(https://support.industry.siemens.com/cs/ww/en/ps/22143/man).
You will find the supported object groups and variations in the section Datapoint types
(Page 59).
Communications partner (DNP3) can be:
– SIMATIC PCS7 TeleControl
– SIMATIC WinCC TeleControl
– SIMATIC WinCC OA
– A TIM module with DNP3 capability (TIM 3V IE DNP3 / TIM 4R IE DNP3)
For the manual of the TIM module see /5/ (Page 120).
– Third-party systems that support the DNP3 specification named above.
●
IEC 60870-5-104
The CP functions as a substation (slave).
Communication is based on the specification IEC 60870-5 Part 104 (2006).
You will find a detailed overview of the attributes and properties specified in the IEC
specification and supported by the CP in the IEC device profile, see Link:
(https://support.industry.siemens.com/cs/ww/en/ps/22143/man).
You will find the supported IEC type identifiers as in the section Datapoint types
(Page 59).
Communications partner (IEC master) can be:
– SIMATIC PCS7 TeleControl
– SIMATIC WinCC TeleControl
