Application and functions
1.6 Compatibility with the previous product
CP 342-5 / CP 342-5 FO
24 Manual, 07/2017, C79000-G8976-C146-10
Note
What to do with a slot left empty
If you cannot eliminate gaps in the slots left by replacing modules by closing up the
remaining modules, you will need to use a dummy module (6ES7 370
-0AA01-0AA0). The
dummy module is is not configured and does not occupy any address space.
In this case, t
he address switch on the rear of the module must be set to "Non Address
Mode" (NA).
1.6.3
Compatibility in the user program in DP mode
Device-dependent differences on the program block interface
Compared with previous modules, the CP 342-5/342-5 FO reacts differently in the following
ways. Remember the effects in your user program. The following table provides an overview:
Table 1- 3 Changes in response
Topic / relates to
Response of the device types
CP 342-5 6GK7 342-5DA00-0XE0
CP 342-5 6GK7 342-5DA01-0XE0
New response of the device types
CP 342-5 6GK7 342-5DA02-0XE0
CP 342-5 6GK7 342-5DF00-0XE0
CP 342-5 6GK7 342-5DA03-0XE0
1. DPSTATUS output parameter
in program block DP_RECV
DP master mode: Bit 6: Display of "received data
overflow"
Bit 6: is no longer set
DP slave mode:
Bit 3: Display of "No frame from DP
master within the watchdog time"
Bit 4: Display of "DP data overflow"
Bit 3: is no longer set
Bit 4: is no longer set
2. DP modes A distinction is made between
STOP and OFFLINE.
The STOP mode is mapped to the OFFLINE
mode.
3. Set current DP mode - is supported - With the version of the CP 342-5 described
here, the following job parameters are no
longer supported for program block DP_CTRL
with CTYPE 4:
• RUN with AUTOCLEAR
• RUN without AUTOCLEAR
