Notes on operation
4.3 Interface in the user program (status of blocks)
CP 342-5 / CP 342-5 FO
38 Manual, 07/2017, C79000-G8976-C146-10
4.3
Interface in the user program (status of blocks)
Status displays with the program block AG_SEND
For the CP 342-5 (6GK7 342-5DA03-0XE0), note the following over and above the
information in /4/ (Page 48), Release 03/2010:
DONE
ERROR
STATUS
Meaning
0 1 8315
H
Possible additional meaning:
This error code can also occur with bus problems (for example physical disturb-
ances due to bad cable connections or different settings for the transmission speed
on the nodes).
Status displays with the program block DP_DIAG
For the CP 342-5 (6GK7 342-5DA03-0XE0), note the following over and above the
information in /4/ (Page 48), Release 03/2010:
DONE
ERROR
STATUS
Possible
with DTYPE
Meaning
1 0 0000
H
0, 1
and 4-9
Job completed without error
Note:
With DTYPE 2, 3 and 10, error-free execution is indicated by a status
code other than "0". Below (see table DP_DIAG codes in /4/ (Page 48)),
you will see the detailed status codes for error-free execution for the
range:
82
XX
H
If an error occurs in execution, you receive status codes in the following
ranges:
80XX
H
, 83XX
H
, 8FXX
H
1 0 8248
H
2, 3, 10 Job completed without error
Note: This is the default code for the named diagnostics types if there is
no special situation to signal.

Siemens CP 342-5 Specifications

General

Category	Communication Processor
Interface	PROFIBUS DP
PROFIBUS Baud Rate	9.6 kbps to 12 Mbps
Number of DP slaves	Up to 125
Power supply	24 V DC
Mounting	DIN rail
Digital inputs	No
Digital outputs	No
Operating temperature	0°C to 60°C
Current consumption	100 mA typical
