Technical Specifications
23
CP 5611 Installation Instructions/Product Information
A5E00102070–01
Technical Specifications
Tabelle 6-1
Dimensions Short PCI module format
(102 mm x 130 mm)
Weight Approx. 100 g
Module insertion PCI bus direct plug–in (32–bit)
Bus interface PCI V2.1, PnP
Electrical Values
Operating voltage Safety extra–low voltage (SELV) com-
plying with EN60950
Rated voltage (limit values) 5 VDC (4.75 to 5.25 V)
Current consumption at rated
voltage
max. 500 mA
Connector 9-pin sub D female connector with
screw locking mechanism.
Type of transmission RS 485 floating within the SELV limits
Transmission rate 9.6 Kbps to 12 Mbps
Mode on the MPI/DP inter-
face
Floating (interface signals) non–floating
(cable shield)
