Page #6 background image
6
Siemens
A6V11393935_en--_c
Smart Infrastructure
2020-09-01
Technical data
Power data
Power supply
Operating voltage (SELV/PELV)
AC 24 V +/-20%
Frequency
50 or 60 Hz
Power consumption
6.5 VA max.
Transformer requirements and recommended voltages
Type
Class 2, AC 24 V, 50 / 60 Hz, SELV, PELV
Functional data
Functional data
Nominal torque
10 Nm
Nominal rotary angle
90°
Maximum rotary angle
95° ± 2°
Runtime for 90° rotary angle
150 s
Shaft size
8…16 mm, round
8…10 mm, round (with centering insert)
6…12.8 mm square
Minimum shaft length
20 mm
Pressure sensor
Pressure sensor
Measurement range
0…500 Pa
Sample rate
≤ 500 ms
Overload range
0…100 kPa
Measuring range accuracy
Zero point accuracy
Resolution
3%
0.2 Pa
12 Bit
Connections
Interfaces
Ethernet
Plugs: dual RJ45, 10M/100M fast Ethernet
Interface type: IEEE 802.3 compliance
Cable type: 100M STP CAT 5
USB (2.0)
Type Micro B
Conformity
Ambient conditions and protection classification
Classification per IEC/EN 60730
Function of automatic control devices
Pollution degree
Overvoltage category
Type 1
2
III
Design type
Device suited for use with equipment of safety
