A5E32282889 XPS Series Transducers – QUICK START MANUAL Page EN-5
mmmmm
English
Specifications
* Universal flange fits ANSI, DIN, and JIS standards.
** Approximate shipping weight of transducer with standard cable length.
*** EMC performance available upon request.
XPS-10 XPS-15 XPS-30
Measurement Range
0.3 - 10 m
(1 - 33 ft)
0.3 - 15 m
(1 - 50 ft)
0.6 - 30 m
(2 - 100 ft)
Frequency (kHz) 44 44 30
Beam Angle
12 6 6
Environmental
Location
indoor/outdoor indoor/outdoor indoor/outdoor
Maximum
Altitude (m)
2000 2000 2000
Ambient
Temp era tu re
-40 to 95 C
(-40 to 203 F)
-40 to 95 C
(-40 to 203 F)
-40 to 95 C
(-40 to 203 F)
Pressure
8 bar
(120 psi)
8 bar
(120 psi)
Europe: 0.5 bar
N. America: 15 psi
Pollution Degree
44 4
Construction
Housing
PVDF PVDF PVDF
Mounting
1" NPT or
BSP conduit connection
1" NPT or BSP conduit
connection
1-1/2" NPT or BSP conduit
connection
Options
• factory bonded to suit ANSI, DIN, and JIS standards
• polyethylene foam facing for dusty or steamy environments
• submergence shield, where flooding can occur (available only
for XPS-10, XPS-15)
• split flange for field mounting to suit ANSI, DIN, and JIS
standards
Cable
2-wire twisted pair/braided and foil shielded, 0.5mm² (20
AWG), PVC jacket
• 2-wire twisted pair/
braided and foil
shielded, 0.5mm² (20
AWG), PVC jacket
Maximum separation:
100 m
(330 ft)
• RG-62 A/U coax
Maximum separation:
365 m (1200 ft)
Weight**
0.8 kg
(1.7 lb)
1.3 kg
(2.8 lb)
4.3 kg
(9.5 lb)
Maximum
Separation
365 m
(1200 ft)
365 m
(1200 ft)
365 m
(1200 ft)
Supply Source Transducers shall only be supplied by Siemens Milltronics certified controllers
Approvals
CE***, CSA, FM, IECEx/ATEX, INMETRO: See nameplate or consult Siemens Milltronics for
current approvals.
