Siemens FC924 Installation Instructions

25
Siemens Industry, Inc. A6V10356958_en--_n
Smart Infrastructure
VN2002-A1 Ethernet module (MM) 0.000 0.000 35 mA(standby) 36mA(active) per module
VN2003-A1 Ethernet module (SM) 0.000 0.000 35mA(standby) 36 mA(active) per module
VCI2003-A1 VoIP module 0.000 0.000 43 mA (standby), 43 mA (alarm) per module
VTO2001-U2/-U3 Option module (24 Switches) 0.000 0.000
16mA (standby) 143mA (active)
VTO2004-U2/-U3 Option module (Microphone) 0.000 0.000 29mA (standby) 54 mA (active)
FCA2031-A1 Connection module (MoNet) 0.000 0.000 1 mA (standby), 1 mA (alarm) per module
FN2012-A1 Ethernet switch (modular) 0.000 0.000 340 mA (standby), 340 mA (alarm) per module
FT2007-U1 LED annunciator driver 0.000 0.000
25 mA (standby), 250 mA (max)
FT2008-U1/-R1
Tabular annunciator (16 z,
color) 0.000 0.000
25 mA (standby), 65 mA (max)
FT2009-U1/-R1
Tabular annunciator (32 z,
color) 0.000 0.000 25 mA (standby), 105 mA (max)
FCL2004-U1 MXL Device Interface Module 0.000 0.000 130mA + 1.5mA per device
Connect X300
Gateway CXG3-X300 Connect X300 0.000 0.000 259 mA per module
Devices Description Qty Stdby/Alm
Current
Draw
HFP-11 Photo-thermal detector 0.00000 1.4 mA per device
HFPO-11 Photo detector 0.00000 1.4 mA per device
HFPT-11 Thermal detector 0.00000 1.4 mA per device
OOHC941
Dual optical/thermal/CO
detector 0.00000 0.75 mA per device
OOH941 Dual optical/thermal detector 0.00000 0.68 mA per device
OH921 Photo-thermal detector 0.00000 0.28 mA per device
OP921 Photo detector 0.00000 0.28 mA per device
HI921 Thermal detector 0.00000 0.28 mA per device
FDCIO422 4-input/4-output module 0.00000 1.0 mA per device
HMS / 8700-S-D-
M Manual station 0.00000 1.4 mA per device
HTRI-S / 8702 Single input module 0.00000 1.4 mA per device
HTRI-D / 8703 Dual input module 0.00000 1.4 mA per device
HTRI-R / 8704 Single input/single relay Mod 0.00000 1.4 mA per device
XTRI-S
Addressable Switch Interface
Mod w/ Dual Isolators (single
input)
0.00000
0.65 mA per device
XTRI-D
Addressable Switch Interface
Mod w/ Dual Isolators (Dual
input)
0.00000
0.95 mA per device
XTRI-R
Addressable Switch Interface
Mod w Dual Isolators (w/ relay)
0.00000
0.75 mA per device
XTRI-M
Addressable Switch Interface
Mod w/ Dual Isolators (compact
size)
0.00000
0.65 mA per device
XMS-D Double action pull station
0.00000
0.50 mA per device
XMS-M Single action pull station
0.00000
0.50 mA per device
XMS-S Single action pull station
0.00000
0.50 mA per device
ILED-XW
Intelligent Remote Lamp – Wall
mount (rectangular plate)
0.00000
0.50 mA per device
ILED-XC
Intelligent Remote Lamp –
Ceiling mount (round plate)
0.00000
0.50 mA per device
TSM-1X
Intelligent Test Switch Module
with Isolators
0.00000
0.50 mA per device
HZM / 8705 Conventional zone module 0.00000 1.4 mA per device
HCP / 8706 Addressable control point 0.00000 1.4 mA per device
HLIM Loop Isolator Module 0.00000 1.0 mA per device
ILED /8726 Intelligent LED 0.00000 1.4 mA per device
PAD-5 Power Expander Main Board 0.00000 0.75 mA per expander
PAD-5-CDC
Conventional Detector
Expansion Board 0.00000 0.75 mA per board
