Siemens FLENDER H1SH User Manual

14 / 96
BA 5030 en 02/2013
1.4.1.1 Measuringsurface soundpressure level for bevelhelical gear units (B...) without fan
Table 6: Measuringsurface soundpressure level L
pA
in dB(A) for bevelhelical gear units without fan
Type
i
N
n
1
1/min
Gearunit size
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
B2
5 1500 70 71 72 75 78 80 82 83 84 86 87 88 89 90 93 - - - - - - -
. 1000 64 65 66 70 72 73 76 77 78 79 81 82 83 84 86 88 89 - - - - -
8
750 1) 1) 1) 63 65 66 69 71 72 73 74 75 77 78 80 82 83 84 - - - -
9 1500 65 66 67 71 74 75 77 79 80 81 83 84 85 86 87 89 - - - - - -
. 1000 59 60 61 65 67 69 72 73 74 76 77 78 80 81 82 83 85 86 - - - -
14
750 1) 1) 1) 1) 60 63 65 66 67 69 71 72 73 74 76 77 78 79 - - - -
16 1500 62 65 63 66 69 71 72 74 75 77 78 80 81 82 85 85 - - - - - -
. 1000 1) 1) 1) 61 63 65 67 68 69 71 72 74 75 77 79 80 81 81 - - - -
22.4
750 1) 1) 1) 1) 1) 1) 60 62 63 64 66 67 68 70 72 73 74 75 - - - -
B3
12.5 1500 - - 65 68 71 74 75 76 77 79 81 83 84 85 86 87 87 88 89 90 91 92
. 1000 - - 1) 63 66 68 69 70 72 73 75 77 78 80 80 81 82 82 84 85 86 86
31.5
750 - - 1) 1) 1) 61 62 64 65 66 68 71 71 73 73 74 75 75 77 78 79 79
35.5 1500 - - 60 65 67 70 71 71 72 74 77 79 80 81 82 83 83 84 86 86 88 88
. 1000 - - 1) 1) 62 65 65 66 66 69 71 73 75 76 76 77 77 78 80 81 82 83
56
750 - - 1) 1) 1) 1) 1) 1) 1) 62 65 67 68 69 70 70 71 72 74 74 75 76
63 1500 - - 1) 61 64 70 67 68 68 70 73 75 76 78 78 79 79 80 82 83 84 84
. 1000 - - 1) 1) 1) 63 62 62 62 65 68 70 71 72 73 73 74 75 76 77 78 79
90
750 - - 1) 1) 1) 1) 1) 1) 1) 1) 61 63 64 65 66 67 67 68 70 70 72 72
B4
80 1500 - - - - 64 65 67 68 70 72 75 76 77 79 80 81 82 83 84 85 86 86
. 1000 - - - - 1) 1) 61 63 64 67 69 70 72 73 74 75 76 77 78 79 80 80
125
750 - - - - 1) 1) 1) 1) 1) 1) 62 64 65 66 68 68 69 71 71 72 73 74
140 1500 - - - - 60 61 63 65 66 68 71 72 73 75 76 77 78 79 80 81 82 82
. 1000 - - - - 1) 1) 1) 1) 61 63 65 67 68 69 71 71 72 74 75 75 76 77
224
750 - - - - 1) 1) 1) 1) 1) 1) 1) 1) 61 62 64 65 66 67 68 69 69 70
250 1500 - - - - 1) 1) 1) 62 63 65 67 69 70 71 73 73 75 76 77 77 78 79
. 1000 - - - - 1) 1) 1) 1) 1) 1) 62 63 64 66 67 68 69 70 71 72 73 73
400
750 - - - - 1) 1) 1) 1) 1) 1) 1) 1) 1) 1) 1) 61 62 63 64 65 66 66
1) L
pA
< 60 dB(A)
