Document ID: 009906_d_en_GB
Edition: 05.2009
2 of 4
Switching off detector zones / detectors
The following example represents a possible operation sequence:
DANGER
System parts that have been switched off make it impossible to detect fires or
faults!
Fire may spread unhindered.
The area that has been switched off must be manually supervised.
System parts that have been switched off must be switched back on as soon as possible.
Switching off a detector zone (password required)
Step Result
1.
Press the button to open the main menu.
(Password required)
Main menu
Exit with <C>
Access level 2.1
Message summary
Functions
Favorites
Topology
(1)
(2)
(3)
(4)
Element search
Event memory
Log in / logout
Settings / administration
(5)
(6)
(7)
(8)
Function
On/Off
Function
All
LED
Test
2.
Press <2> to open the menu item "Functions".
Note:
The numbers in brackets (1)… can be entered
with the numeric keys <1>… below the main
menu button.
Functions
Exit with <C>
Access level 2.1
On / Off
Test
Activate / deactivate
Information
(1)
(2)
(3)
(4)
Configuration
Maintenance
All functions
(5)
(6)
(7)
Function
On/Off
Function
All
LED
Test
3.
Press <1> "On/Off".
Select element category
Zone
Area
Section
Detector
RT control
(1)
(2)
(3)
(4)
(5)
4.
Press <3> "Section".
Note:
A British Standard zone is called a Section in this
system’s.
Enter address
Zone no ---------
Confirm with <ok> / Exit with <C>
Delete with <Cursor up>
5.
Enter a zone number, if known, or press <ok>
without entering a number.
Note:
The example shows the result, after confirmation
with <ok> without entering an address.
004 Sections
Second Floor
First Floor
Ground Floor
Basement
Zone no 4
Zone no 3
Zone no 2
Zone no 1
Execute
command
Show
Topology
6.
Scroll with the navigation buttons to the
zone you want to switch off.
The selected zone is marked by a frame.
Press <Softkey 1> "Execute command".
Select command
All zones OFF
MCP zones OFF
Non-MCP zones OFF
(4)
(5)
(6)
7.
Press <4>, <5> or <6> according to the zone
types required to be switched off.
Command response confirms the execution.
The zone has been switched off.
The LED "ISOLATION" is on.
