Siemens FT2040 User Manual

Document ID: 009906_d_en_GB Edition: 05.2009
3 of 4
Switching off a detector (Password required)
Step Result
1.
Press the button to open the main menu.
(Password required)
⇒
Main menu
Exit with <C>
Access level 2.1
Message summary
Functions
Favorites
Topology
(1)
(2)
(3)
(4)
Element search
Event memory
Logout / change level
Settings / administration
(5)
(6)
(7)
(8)
Function
On/Off
Function
All
LED
Test
2.
Press <4> to open the menu item "Topology".
Note:
The numbers in brackets (1)… can be entered
with the numeric keys <1>… below the main
menu button.
⇒
Topology
Exit with <C>
Access level 2.1
Detection tree
Hardware tree
Control tree
(1)
(2)
(3)
Function
On/Off
Function
All
LED
Test
3.
Press <1> "Detection tree".
Scroll with the navigation buttons to the
area within which is the detector that you want to
switch off.
The selected area is marked by a frame.
⇒
002 Items Detection tree
Main Building
Annex Building
Area
Area
Lower
level
Execute
commands
4.
Press Softkey <2> "Lower level".
Scroll with the navigation buttons to the
section within which is the detector that you want
to switch off.
The selected section is marked by a frame.
Note:
As an alternative to switching off a zone (page 2)
executing commands at this point will then lead to
the menu item to switch a whole zone of detectors
off.
⇒
004 Items Area
Main Building
Second Floor
First Floor
Ground Floor
Basement
Zone no 4
Zone no 3
Zone no 2
Zone no 1
Upper
level
Lower
level
Execute
commands
5.
Press Softkey <2> “Lower level".
Scroll with the navigation buttons to the
zone (=detector in this system’s terminology) you
want to switch off.
The selected detector is marked by a frame.
⇒
005 Items Zone no 2
Ground Floor
1/01 Reception hall Zone no 2
1/02 Corridor MCP Zone no 2
1/03 Storage room Zone no 2
1/04 Meeting room Zone no 2
Upper
level
Lower
level
Execute
commands
6.
Select a detector and press Softkey <3> Execute
commands".
⇒
Select command
OFF (2)
7.
Press <2> "OFF" (switch off).
⇒
⇒ Command response confirms the execution.
⇒ The detector is switched off.
⇒ The LED "ISOLATION" is on.
