Siemens FT2080 Mounting & Installation

Setup of fire terminal (Touch) FT2080
1
5 |
24
Building Technologies
A6V10462660_en
--
_b
Fire Safety
2016
-
04
-
08
1 Setup of fire terminal (Touch) FT2080
Figure 1: Rear panel fire terminal (Touch) FT2080
1 Support plate
2 Front indicator (Touch) FTO2010
3 PMI & mainboard FCM2027
4 4x mounting holes in the operating unit
5 Shield plate above carrier (CPU)
6 Hinges for wall housing
4
6
2
3
5
6
4
1
4
4

Siemens FT2080 Specifications

General

Brand	Siemens
Model	FT2080
Category	Touch terminals
Language	English
