6 Technical data
Supply input Voltage DC 20…30 V
Quiescent current (display illumination
dimmed 15%)
390 mA
Maximum current (display illumination
100% and lamp test active)
700 mA
Display Screen size 12"
Resolution 1280 x 800 pixels
Interfaces 2x slots for serial modules ● RS232 module for event printer
● RS485 module for ESPA-4.4.4
interface, FAT, FBF, UGA or remote
EVAC-NL operation
2x slots for network modules
(SAFEDLINK)
● Full functionality incl. degraded
mode function
● Degraded mode function only
1x Ethernet connection RJ45 10/100 Mbit/s
1x connection for peripheral data bus X400
Ambient conditions Operating temperature -8…+42 °C
Storage temperature -20…+60 °C
Moisture, condensation not permitted Max. 95 % rel.
Protection category (IEC60529) IP30
Mechanical data Dimensions (W x H x D) 427 x 200 x 25 mm
Weight without options ● FT2080-A1: 2.544 kg
Color
Foil: ∼RAL9010 Pure white,
∼RAL9006 White aluminum
Standards and approvals VdS G215024
Siemens Switzerland Ltd; Gubelstrasse 22
CH-6301 Zug
Technical data: see doc.
008836
14
FT2080 - Control and Indicating Terminal for use in fire detection and fire alarm systems installed in buildings.
2014/30/EU (EMC): EN 50130-4 / EN 61000-6-3 ; 2014/35/EU (LVD): EN 60950-1 ; 2011/65/EU (RoHS): EN 50581
The declared conformity can be seen in the EU Declaration of Conformity (DoC), which is obtainable via the Customer Support Center:
Tel. +49 89 9221-8000 or http://siemens.com/bt/download
DoC No.: CED-FT2080
FT2080-A1 / FT2080-C2
