Section 1: Introduction, Page 1—13
Fuse Holder
The fuse holder, in the center of the panel, holds the fuse that protects against serious
electrical overload. A spare fuse is also located in the fuse holder.
ON / OFF Switch
The ON / OFF Switch is located at the bottom of the panel and controls all power to the
instrument.
Specifications
Power Requirements 100 - 230 VAC + 10%, 50/60 Hz, 0.75
Amps
Fuse Rating 250 Volt, 1.0 Amps, 5mm x 20mm, Type T
Line Leakage Current <5 milliamperes
Testing protocol and allowable limits as
specified by the safety standards for
laboratory equipment outlined in UL 1262
and CSA 22.2 No. 151.
Dimensions Depth - 43.4 cm (17.1 in)
Width - 47.0 cm (18.5 in)
Height - 19.0 cm (7.5 in)
Weight 17.7 kg (39 lbs)
Throughput Stains 1 slide per minute
