Siemens ISGS User Manual

ISGS Settings Worksheet for Date: Set B
Siemens Energy & Automation, Inc. S-19
B1700 Phase Time Overcurrent (51)
B1702 Curve 51 Inverse Short Inverse Long Inverse
Moderately
Inverse
Custom Very Inverse Extremely Inverse Definite Inverse
Slightly Inverse
I
2
T without Limit
B1703 Pickup 51 5 A CT 0.5 A Range: 0.5-20 A (0.1 A steps) A
(PU point is 1.06 1 A CT
of PU setting).
0.1 A Range: 0.1-4 A (0.1 A steps) A
B1705 Time Dial 51 0.1 Range: 0.1-9.9 (0.1 steps)
B1706 Filter 51 rms fundamental
B1709 Reset 51 Disk Emulation Instantaneous
1710 Freeze Waveform 1 51 Settings displayed or changed here apply to both parameter sets
1711 Freeze Waveform 2 51 Settings displayed or changed here apply to both parameter sets
B1712 Block 51 by None 50HS & 50HSN 50HS 50HSN
B1800 Neutral Time Overcurrent (51N)
B1801 Function 51N Enabled Disabled
B1802 Curve 51N Inverse Short Inverse Long Inverse
Moderately
Inverse
Custom Very Inverse Extremely Inverse Definite Inverse
Slightly Inverse
I
2
T without Limit
B1803 Pickup 51N 5 A CT 0.5 A Range: 0.5-20 A (0.1 A steps) A
1 A CT 0.1 A Range: 0.1-4 A (0.1 A steps) A
B1805 Time Dial 51N 0.1 Range: 0.1-9.9 (0.1 steps)
B1806 Filter 51N rms fundamental
B1809 Reset 51N Disk Emulation Instantaneous
1810 Freeze Waveform 1 51N Settings displayed or changed here apply to both parameter sets
1811 Freeze Waveform 2 51N Settings displayed or changed here apply to both parameter sets
B1812 Block 51N by None 50HS & 50HSN 50HS 50HSN
S
isv3o_1.bk : isv3o_cf.frm Page 19 Wednesday, August 7, 1996 10:51 AM
