Siemens LMV3 series Service Manual

19
Block 300: Burner control (only with LMV26)
Param. Descrizione Description Password
LMV20 LMV27 LMV26 LMV37
301
Combustibile 1 : Modalità funzionamento bru-
ciatore ( rampa combustibile, modulante /
multistadio, servocomandi, ecc.)
__= non definito (cancellazione curve)
1 = accensione diretta a gas (G mod)
2 = accensione tramite pilota gas con attacco
tra le due elettrovalvole EV1/EV2 del gas
(Gp1 mod)
3 = accensione tramite pilota gas con attacco
a monte dell’elettrovalvola EV1 del gas (Gp2
mod)
4 = accensione a gasolio - modulante (Lo
mod)
5 = accensione a gasolio - bistadio (Lo 2
stage)
6 = accensione a gasolio - tristadio (Lo 3
stage)
7 = accensione diretta a gas - regolazione
pneumatica (G mod pneu)
8 = accensione tramite pilota gas con attacco
tra le due elettrovalvole EV1/EV2 del gas -
regolazione pneumatica (Gp1 mod pneu)
9 = accensione tramite pilota gas con attacco
a monte dell’elettrovalvola EV1 del gas -
regolazione pneumatica (Gp2 mod pneu)
10 = olio modulante con accensione tramite
pilota (LOGp mod)
Fuel 1 : Burner operating mode (fuel train,
modulating / multistage, actuators, etc..)
__= undefined (delete curves)
1 = gas direct ignition (G mod)
2 = ignition by gas pilot connected between
the two gas solenoid valves EV1/EV2 (Gp1
mod)
3 = ignition by gas pilot connected upstream
the gas EV1 (Gp2 mod)
4 = light oil ignition - modulating (Lo mod)
5 = light oil ignition - double stage (Lo 2 stage)
6 = light oil ignition - three stage (Lo 3 stage)
7 = gas direct ignition - pneumatic regulation
(G mod pneu)
8 = ignition by gas pilot connected between
the two gas solenoid valves EV1/EV2 - pneu-
matic regulation (Gp1 mod pneu)
9 = ignition by gas pilot connected upstream
the gas EV1 - pneumatic regulation (Gp2 mod
pneu)
10 = LoGp mod
OEM / Service x
