Siemens M1 - AT&F - Load Factory Profile; AT&V - Display Configuration

25
GSM M1 Module, English: A24859-N4000-A100-1-7677
gsm-m1-e.fm
Technical reference section
6.3.96
This command allows you to load the factory profile that was supplied with the GSM
module.
The AT&V0 command allows you to display the active configuration profile on the screen.
Enter: AT&V
The GSM module then transfers the information to the computer, which displays it on
the screen.
Example:
You have a GSM module and have loaded the factory configuration by means of the
AT&F command. Now enter the AT&V command. The following is displayed on the
screen:
AT&V
ACTIVE PROFILE:
B99 E1 L2 M1 Q0 V1 X4 Y0 %D0 &C1 &D2 &G0 &Y0
S00:000 S01:000 S02:043 S03:013 S04:010 S05:008 S06:002 S07:060 S08:002
S09:006 S10:007 S12:050 S14:6AH S16:00H S18:000 S21:30H S22:46H S23:1CH
S25:005 S26:001 S27:00H
0
STORED PROFILE 0:
B99 E1 L2 M1 Q0 V1 X4 Y0 &C1 &D2 &G0
S00:000 S14:6AH S18:000 S21:30H S22:46H S23:1CH S25:005 S26:001 S27:00H
x S27:00H
STORED PROFILE 1:
B99 E1 L2 M1 Q0 V1 X4 Y0 &C1 &D2 &G0
S00:000 S14:6AH S18:000 S21:30H S22:46H S23:1CH S25:005 S26:001 S27:00H
x S27:00H
TELEPHONE NUMBERS:
&Z0=
&Z1=
&Z2=
&Z3=
OK
AT&F - Load factory profile
AT&F
Option Result
AT&F If your GSM module stops functioning due to a faulty configuration,
this command resets the module to the factory configuration.
AT&V - Display configuration
