Siemens M1 - GSM Modes; Fax; Data; Sms

72
gsm-m1-e.fm
GSM M1 Module, English: A24859-N4000-A100-1-7677
Technical data
26.2.96
CCITT Rec.: CCITT T.30, T.4
Routes: MOC and MTC
Info.transf.mode: FAX G3
Clock mode: Synchronous
Connection elem.: Transparent
Structure: Unstructured
Radio channel: Full rate
Intermed. rate: 8 or 16 kbit/s
User rate: 2400, 4800 or 9600 bit/s
Teleservice: TS 61, TS 62
GSM Rec.: GSM 7.01, 7.02, 4.21
Routes: MOC and MTC
Info.transf.mode: 3.1 Khz audio ex PLMN (analog) or
UDI/V.110 (ISDN)
Clock mode: Asynchronous
Connection elem.: Transparent
Structure: Unstructured
Layer 2 protocol: NAV
Data bits: 8
Parity bits: None
Bits/char. Always 10 bits/char.
Stop bits: 1
Radio channel: Full rate
Intermed. rate: 8 or 16 kbit/s
User rate: 2400, 4800 or 9600 bit/s
Modem type: V.22bis, V.32
Bearer service: BS 24, BS 25, BS 26
GSM Rec.: GSM 03.40, 07.05
Routes: SMS MO and MT
Mode: PDU mode
Teleservice: TS22, TS21
GSM modes
Fax
Data
SMS
