Siemens M1 - Page 68

67
GSM M1 Module, English: A24859-N4000-A100-1-7677
gsm-m1-e.fm
Technical reference section
6.3.96
S22: Result codes
Bit Options Values
0 Reserved 0
1 Reserved 0
2 Reserved 0
3 Reserved 0
4
5
6
Result code options (ATXn)
0
1
2
3
4
5
6
7
Same as ATX0
Reserved
Reserved
Reserved
Same as ATX1
Same as ATX2
Same as ATX3
Same as ATX4
7 Reserved 0
S23: Bit rate and parity
Bit Options Values
0 Reserved 0
1
2
3
Transfer rate at the
COM interface
0
1
2
3
4
5
6
7
Reserved
Reserved
Reserved
2400 bit/s
4800 bit/s
9600 bit/s
19200 bit/s
Reserved
4
5
Parity
0
1
2
3
Reserved
None
Reserved
Reserved
6 Reserved 0
7 Reserved 0
