English 3. INSTALLATION – MIDIMASTER Vector
G85139-H1751-U529-D1 © Siemens plc 199
9
4/8/99
26
Depth D
H1
Depth D
H
H
H1
Æ
Æ
= 8.5 mm
Frame Sizes 4, 5 and 6
4 bolts M8
4 nuts M8
4 washers M8
W1
W1
W
W
Æ
Æ
= 8.5 mm
6 bolts M8
6 nuts M8
6 washers M8
Frame Size 7
Figure 3.1.2: Mechanical Installation Diagram - MIDIMASTER Vector
