Siemens MICROMASTER Vector User Manual

6. SYSTEM PARAMETERS English
Parameter Function Range
[Default]
Description / Notes
© Siemens plc 1999 G85139-H1751-U529-D1
49
4/8/9
9
P045
Inversion fixed setpoints for
fixed frequencies 1 - 4
0 - 7
[0]
Sets the direction of rotation for the fixed frequency:
FF 1 FF 2 FF3 FF 4
P045 = 0
Þ
ÞÞ Þ
P045 = 1
Ü
ÞÞ Þ
P045 = 2
Þ
ÜÞ Þ
P045 = 3 ÞÞ Ü Þ
P045 = 4 ÞÞ Þ Ü
P045 = 5
Ü
ÜÞ Þ
P045 = 6 ÜÜ Ü Þ
P045 = 7 ÜÜ Ü Ü
Þ Fixed setpoints not inverted.
Ü Fixed setpoints inverted.
P046 ·
Fixed frequency 5 (Hz) 0 - 650.00
[25.0]
Valid if P006 = 2 and P051 = 6 or 18. , or P053-55=17
P047 ·
Fixed frequency 6 (Hz) 0 - 650.00
[30.0]
Valid if P006 = 2 and P356 = 6 or 18, or P053-55=17
P048 ·
Fixed frequency 7 (Hz) 0 - 650.00
[35.0]
Valid if P006 = 2, and P053-55=17
P049 ·
Fixed frequency 8 (Hz) 0 - 650.00
[40.0]
Valid if P006 = 2, and P053-55=17
P050
Inversion fixed setpoints for
fixed frequencies 5 - 8
0 - 7
[0]
Sets the direction of rotation for the fixed frequency:
FF 5 FF 6 FF7 FF8
P050 = 0
Þ
ÞÞ Þ
P050 = 1
Ü
ÞÞ Þ
P050 = 2
Þ
ÜÞ Þ
P050 = 3 ÞÞ Ü Þ
P050 = 4 ÞÞ Þ Ü
P050 = 5
Ü
ÜÞ Þ
P050 = 6 ÜÜ Ü Þ
P050 = 7 ÜÜ Ü Ü
Þ Fixed setpoints not inverted
Ü Fixed setpoints inverted
