Siemens NK8232

Structure and functions
NK823x hardware
4
27
Building Technologies
A6V10062437_a_en
Fire Safety & Security Products 30.06.2013
4.2.3 Internal jumpers
The internal jumpers are used for:
 X115: When closed, it disables the box tamper alarm.
Internal DIP switch and jumpers (NKM8001-A1 mainboard)
Item Name Description
1 S101 DIP-Switches
2 S1 Reset button
3 S2 Tamper switch
4 X115 When closed, it disables the box tamper alarm.
