5.8 Designation plate FDBZ291
1. Label designation plate FDBZ291 with location address of point detector.
2. Attach designation plate FDBZ291 to detector base DB72x or sounder base
DBS720.
If the detector base seal RS720 is being used, it is not possible to install the
designation plate FDBZ291.
Figure 9: Installation of designation plate FDBZ291
