Siemens OpenAir GEB141.1P

Technical Instructions OpenAir GEB Series Enhanced Rotary Non-Spring Return Damper Actuators
Document Number A6V12029156
December 16, 2021
Page 14 Siemens Industry, Inc.
Table 2.
Actuators
Symbol
Function
Terminal
Designations
Color
Color
Abbreviation
24 Vac
Actuator
1
Supply (SP)
G
Red
RD
2
System neutral (SN)
G0
Black
BK
6
Control signal clockwise
Y1
Violet
VT
7
Control signal counterclockwise
Y2
Orange
OG
8
0 (2) to 10 Vdc input signal
Y
Gray
GY
9
Output for 0 to 10 Vdc position indication
U
Pink
PK
100 to 240V
Actuator
3
Line (100 to 240 Vac)
L
Brown
BR
4
Neutral
N
Blue
BU
6
Control signal clockwise (GEB34..1U)
Y1
Black
BK
7
Control signal counterclockwise (GEB34..1U)
Y2
White
WH
1
System potential 24 Vdc aux. power supply
G+
Red
RD
2
System Neutral auxiliary power supply
G-
Black
BK
8
Input signal (GEB361.1U)
Y
Gray
GY
9
Output signal (GEB361.1U)
U
Pink
PK
Auxiliary
Switches
S1
Switch A Common
Q11
Gray/
red
GYRD
S2
Switch A N.C.
Q12
Gray/
blue
GYBU
S3
Switch A N.O.
Q14
Gray/
pink
GYPK
S4
Switch B Common
Q21
Black/
red
BKRD
S5
Switch B N.C.
Q22
Black/
blue
BKBU
S6
Switch B N.O.
Q24
Black/
pink
BKPK
Potentiometer
P1
Feedback Potentiometer 0 to 100% P1 - P2
a
White/
red
WHRD
P2
Feedback Potentiometer Common
b
White/
blue
WHBU
P3
Feedback Potentiometer 100 to 0% P3 - P2
c
White/
pink
WHPK
