Siemens QAA55.110 User Manual

55/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating line operating
level
Function Default value Minimum Max Unit
5895 I
Relay output QX5
None ¦ Compressor 2 K2 ¦ Process revers valve Y22 ¦
Hot-gas temp K31 ¦ El imm heater 1 flow K25 ¦ El imm
heater 2 flow K26 ¦ Div valve cool source Y28 ¦ System
pump Q14 ¦ Cascade pump Q25 ¦ Heat gen shutoff valve
Y4 ¦ El imm heater DHW K6 ¦ Circulating pump Q4 ¦ St
tank transfer pump Q11 ¦ DHW intern circ pump Q33 ¦
DHW mixing pump Q35 ¦ Collector pump Q5 ¦ Collector
pump 2 Q16 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem
buffer K8 ¦ Solar ctrl elem swi pool K18 ¦ El imm heater
buffer K16 ¦ H1 pump Q15 ¦ H2 pump Q18 ¦ H3 pump
Q19 ¦ Heat circuit pump HCP Q20 ¦ 2nd pump speed
HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed
HCP Q23 ¦ Diverting valve cooling Y21 ¦ Air dehumidifier
K29 ¦ Heat request K27 ¦ Refrigeration request K28 ¦
Alarm output K10 ¦ Time program 5 K13
None -
5896 I
Relay output QX6
None ¦ Compressor 2 K2 ¦ Process revers valve Y22 ¦
Hot-gas temp K31 ¦ El imm heater 1 flow K25 ¦ El imm
heater 2 flow K26 ¦ Div valve cool source Y28 ¦ System
pump Q14 ¦ Cascade pump Q25 ¦ Heat gen shutoff valve
Y4 ¦ El imm heater DHW K6 ¦ Circulating pump Q4 ¦ St
tank transfer pump Q11 ¦ DHW intern circ pump Q33 ¦
DHW mixing pump Q35 ¦ Collector pump Q5 ¦ Collector
pump 2 Q16 ¦ Solar pump ext exch K9 ¦ Solar ctrl elem
buffer K8 ¦ Solar ctrl elem swi pool K18 ¦ El imm heater
buffer K16 ¦ H1 pump Q15 ¦ H2 pump Q18 ¦ H3 pump
Q19 ¦ Heat circuit pump HCP Q20 ¦ 2nd pump speed
HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed
HCP Q23 ¦ Diverting valve cooling Y21 ¦ Air dehumidifier
K29 ¦ Heat request K27 ¦ Refrigeration request K28 ¦
Alarm output K10 ¦ Time program 5 K13
None -
5909 I
Function output QX4-Mod
None ¦ Source pump Q8/fan K19 ¦ DHW pump Q3 ¦ DHW
intern circ pump Q33 ¦ Instant DHW heater Q34 ¦
Collector pump Q5 ¦ Collector pump 2 Q16 ¦ Solar pump
buffer K8 ¦ Solar pump ext exch K9 ¦ Solar pump swi pool
K18 ¦ Heat circ pump HC1 Q2 ¦ Heat circ pump HC2 Q6 ¦
Heat circ pump HCP Q20
None -
5930 I Sensor input BX1
None ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Collector
sensor B6 ¦ DHW sensor B31* ¦ Hot-gas sensor B82 ¦
Refrig sensor liquid B83 ¦ DHW charging sensor B36 ¦
DHW outlet sensor B38 ¦ DHW circulation sensor B39 ¦
Swimming pool sensor B13 ¦ Collector sensor 2 B61 ¦
Solar flow sensor B63 ¦ Solar return sensor B64 ¦ Buffer
sensor B42 ¦ Common flow sensor B10 ¦ Cascade return
sensor B70 ¦ Special temp sensor 1 ¦ Special temp
sensor 2
None -
5931 I Sensor input BX2
None ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Collector
sensor B6 ¦ DHW sensor B31* ¦ Hot-gas sensor B82 ¦
Refrig sensor liquid B83 ¦ DHW charging sensor B36 ¦
DHW outlet sensor B38 ¦ DHW circulation sensor B39 ¦
Swimming pool sensor B13 ¦ Collector sensor 2 B61 ¦
Solar flow sensor B63 ¦ Solar return sensor B64 ¦ Buffer
sensor B42 ¦ Common flow sensor B10 ¦ Cascade return
sensor B70 ¦ Special temp sensor 1 ¦ Special temp
sensor 2
None -
5932 I Sensor input BX3
None ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Collector
sensor B6 ¦ DHW sensor B31* ¦ Hot-gas sensor B82 ¦
Refrig sensor liquid B83 ¦ DHW charging sensor B36 ¦
DHW outlet sensor B38 ¦ DHW circulation sensor B39 ¦
None -
