Siemens QMX3.P35H Series User Manual

4
Siemens
A6V11521633_en--_b
Smart Infrastructure
2020-11-09
● Do not interchange the wires of the KNX PL-Link cable.
– The red terminal is for KNX PL-Link +
– The gray terminal is for KNX PL-Link –
● Observe all local installation regulations.
CAUTION! The devices are not protected against accidental connection to AC 230 V.
Operation
Operational setting
NOTICE
Operation and display oft he room operator unit depend on the control program of the room
automation station.
Main page displaying HVAC functions for all types (QMX3.P35H…, QMX3.P38H…)
