Siemens RDF300…/RDF340.../RDF400… Basic Documentation CE1P3076en
Building Technologies 4BFunctions 28 Aug 2008
# Parameter
Factory
setting
Setting range
RDF300… RDF340… RDF400…
Expert Level
P30 P-band/Switching differential for heating mode 2K 0.5 … 6 K   
P31 P-band/Switching differential for cooling mode 1 K 0.5 … 6 K   
P33 Dead zone in Comfort mode 2 K 0.5 … 5 K   
P34 Setpoint differential 2 K 0.5 … 5 K   
P35 Integral time 5 min 0…10 min   
P36 Heating/cooling changeover switching point for cooling 16 °C 10…25 °C   
P37 Heating/cooling changeover switching point for heating 28 °C 27…40 °C   
P38 X1 functionality 3 (Op mode
switchover)
0:= NA
1:= Ext/Return air temp
2:= Heat/cool changeover
3:= Operating mode switch
4:= Dewpoint monitor
5:= Enable electrical heater
6:= Alarm input
  
P39 Operating action for X1 if digital input 0 (N.O.) 0:= Normally open
1:= Normally closed
  
P40 X2 functionality 2 (H/C c/o) Same as P38   
P41 Operating action for X2 if digital input 0 (N.O.) 0:= Normally open
1:= Normally closed
  
P44 Runtime for 3-position output (Y11/Y21) 150 s 50…240 sec  U 
P48 Minimum output on-time via on/off control output 1 min. 1...20 minutes  U 
P49 Minimum output off-time via on/off control output 1 min. 1...20 minutes  U 
P50 Purge function (minimum every 2 hours) OFF OFF: Inactive
1…5 min
  
P51 Floor heating limit temperature OFF OFF, 10..50 °C   
P52 Fan operation 1 (Enabled) 0:= Disabled
1:= Enabled
2:= Only in heating
3:= Only in cooling
  
P53 Fan speed 2 (3-speed) 1:= 1-speed
2:= 3-speed
  
P54 Fan overrun time (only when electric heater is used) 60 sec 0 ... 300 sec   
P55 Switching point fan speed high 100% 80..100%   
P56 Switching point fan speed med 65% 30..75%   
P57 Switching point fan speed low 10% 1..15%%   
P58 Fan start kick ON ON: enabled
OFF: disabled
  
P59 Fan minimum on-time 2 min 1 ... 5 min   
P60 Fan kick in Comfort mode (time to next kick) 0 (continuous) 0…89min, OFF   
P61 Fan kick in Energy Saving mode (time to next kick) OFF 0…359min, OFF   
P62 Clean filter reminder runtime OFF OFF, 100 … 9900 hours   
P65 Heating setpoint for Standby (Wheat
Stb
) 8 °C OFF, 5 °C…Wcool
Stb
  
P66 Cooling setpoint for Standby (Wcool
Stb
) OFF OFF, Wheat
Stb
…40 °C   
P69 Temporary setpoint for Comfort mode OFF OFF:= Disabled
ON := Enable
  
P70 Infrared receiver OFF OFF:= Disabled
ON := Enable
U U 
P71 Parameter reset
Set value to ON and confirm by pressing the + and – buttons
OFF OFF:= Idle
ON: = Reset
  
Diagnostic & Test
d01 Application Diagnose 2P:= 2-pipe
2PEL:= 2-pipe & el. heater
4P:= 4-pipe
2P3P:= 2-pipe 3pos
  
d02 Status input X1 Diagnose 0:= Digital input
not activated
1:= Digital input activated
0…49 °C = measured
temp. value
00 := H/C input short
100:= H/C input open
  
d03 Status input X2 Diagnose Same as d02   
d05 Test mode to check the 3-position Y11/Y21 actuator direction.
Note that this parameter can be quit only if the setting is back
at “---” and by pressing + and – buttons
Diagnose “---” := no signal
OPE:= Y11 active
open
CLO:= Y21 active
close
  
