Siemens REV24RF - Connection Diagrams; Application Wiring Examples

16 / 18
Siemens Room temperature controller radio set REV24RF../SET CE1N2206en
Building Technologies 24.04.2008
Connection diagram fro receiver RCR10/868:
L Phase, AC 230 V
N Neutral conductor AC 230 V
Lx Phase, AC 24...250 V
L1 N.O. contact,
AC 24 ….250 V / 16 (2) A
L2 N.C. contact,
AC 24 … .250 V / 16 (2) A
M1 Circulating pump
N2 Receiver RCR10/868
Lx
L1
Y1
M1
N2
Nx
L
N
L2
2255A01
AC 230 V
AC 24...250 V
Lx
Nx
N
L
Y1 Actuating device
Application examples
T
T
F1
F2
N2
M1
Y2
2255S01
N1
T
F1
F2
N2
M1
Y2
2255S02
T T
T
N1
Instantaneous water heater Atmospheric gas burner
N1
Y4
2255S03
Y3
N2
T
N4
T
N3
T
N1
2255S05
E1
N2
Zone valve Cooling unit
