17 / 18
Siemens Room temperature controller radio set REV24RF../SET CE1N2206en
Building Technologies 24.04.2008
Y1
2252S04
M1
N2
T
N1
Circulating pump with precontrol by manual mixing valve
E1 Cooling unit
F1 Thermal reset limit thermostat
F2 Manual reset safety limit thermostat
M1 Circulating pump
N1 Room temperature controller (transmitter) REV24RF..
N2 Receiver RCR10/868
N3 Room temperature controller (transmitter) REV24RF..
N4 Receiver RCR10/868
Y1 3-port valve with manual adjustment
Y2 Magnetic valve
Y3 Three-port valve with actuator
Y4 Two-port valve with actuator
