Installing the Device
2.1General Procedure
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use of
a tool, lock and key, or other means of security, and controlled by the authority re-
sponsible for the location.
2.1 General Procedure
The general procedure for installing the device is as follows:
IMPORTANT
The user is responsible for the operating environment of the device, including main-
taining the integrity of all protective conductor connections and checking equip-
ment ratings. Make sure to review all operating and installation instructions before
commissioning or performing maintenance on the device.
1. Review the relevant certification information for any regulatory requirements.
For more information, refer to "Approvals (Page 51)".
2. Review the RUGGEDCOM RX1500 Series Modules Catalog for special installation
or regulatory requirements related to the modules installed in the device. In the
case of cellular modem line modules, this includes antenna installation and reg-
ulatory requirements.
3. Mount the device.
4. Connect the failsafe alarm relay.
5. Connect power to the device and ground the device to safety Earth.
6. Connect the device to the network.
7. Configure the device.
2.2 Unpacking the Device
When unpacking the device, do the following:
1. Inspect the package for damage before opening it.
2. Visually inspect each item in the package for any physical damage.
3. Verify all items are included.
NOTICE
If any item is missing or damaged, contact Siemens for assistance.
6
RUGGEDCOM RX1501
Installation Manual, 05/2020, C79000-G8976-1054-17
