Siemens RUGGEDCOM RX1501 Installation Guide

RUGGEDCOM RX1501
Installation Guide
Chapter 5
Technical Specifications
Power Supply Specifications 39
Technical Specifications
This section provides important technical specifications related to the device.
CONTENTS
• Section5.1, “Power Supply Specifications”
• Section5.2, “Failsafe Relay Specifications”
• Section5.3, “Operating Environment”
• Section5.4, “Mechanical Specifications”
• Section5.5, “Dimension Drawings”
Section5.1
Power Supply Specifications
NOTE
When determining cable lengths, make sure the minimum input voltage for the power supply is
provided at the power source.
Input Range
Power Supply Type
Min Max
Internal Fuse Rating
Maximum Power
Consumption
a
Insulation
88 VDC 300 VDC
HI
85 VAC 264 VAC
3.15 A(T)
b
65 W
88 VDC 300 VDC
HIP
85 VAC 264 VAC
3.15 A(T)
b
65 W
2800 VDC
for 1 minute
24
24P
13 VDC 36 VDC 10 A(T)
b
63.5 W
48
48P
36 VDC 72 VDC 3.15 A(T)
b
60 W
1500 VDC
for 1 minute
12
12P
9 VDC 15 VDC 12 A 67 W
1500 VAC or 2121
VDC for 1 minute
a
Power consumption varies based on the device configuration.
b
(T) denotes time-delay fuse.

Siemens RUGGEDCOM RX1501 Specifications

General

Brand	Siemens
Model	RUGGEDCOM RX1501
Category	Switch
Language	English
