RUGGEDCOM RX1501
Installation Guide
Chapter 5
Technical Specifications
Dimension Drawings 43
19.7
151.4
102.9
113.3
162.5
Figure29:Line Module Dimensions
162.5
40.6
151.8
102.9
113.4
Figure30:Power Module Dimensions
