Siemens Actuators SAS.., SAT.. for valves CE1P4041en
Smart Infrastructure Handling 2019-04-09
· Without cable gland IP protection is not guaranteed!
· Guide the cable in a loop to the cable gland, so water can drop off.
Prior to installation, the following preconditions must be satisfied:
· Actuator is mechanically connected to a Siemens valve.
· Housing cover is removed.
The actuator has a fixed connection
cable.
As a result, the left cable entry (A) is
used.
1
No: 4
2
PZ 1
3 4
5 6
Observe "
Connection terminals" (page 48)
Notes
Preconditions
Communicating
actuators
Actuator
