Siemens Actuators SAS.., SAT.. for valves CE1P4041en
Smart Infrastructure Connection diagrams and dimensions 2019-04-09
6.4 Dimensions
6.4.1 Stroke actuators
Stroke actuators SA.. with manual adjuster
Typ A
[mm]
B
[mm]
C
[mm]
C1
[mm]
C2
[mm]
D
[mm]
E
[mm]
F
[Zoll] [mm] [mm]
[kg]
1 2
SAS.. / SAT..
151 80 93 21.9 71.1
29.9 21.8 G ¾ 100 200
0.40
M16
1) 3)
M20
1) 3)
SAS../MO
2)
0.55
With ASK39.2: 155 126 248 99 149 0.55
1)
SA..U: ½“ (Ø 21,5 mm)
2)
Device equipped with a fixed connection cable – Left cable entry is used
3)
Thread length max. 9 mm
