Siemens SCALANCE W738-1 M12

Description of the device
4.4 Accessories
SCALANCE W778-1 / W738-1
26 Operating Instructions, 03/2022, C79000-G8976-C450-07
Component
Description
Article number
N-Connect/N-
Connect
female/female
Panel
Feedthrough
Panel feedthrough for wall thicknesses up to a
maximum of 4.5 mm, two N-Connect female
connectors.
6GK5798-2PP00-2AA6
N-Connect/SMA-
Connect
female/female
Panel
Feedthrough
Panel feedthrough for wall thicknesses up to a
maximum of 5.5 mm, two N-Connect/SMA female
connectors.
6GK5798-0PT00-2AA6
4.4.5.5 Antennas
Note
When you select an antenna, keep in mind the national approvals for your device.
You will find more detailed information in Link (
http://www.siemens.com/wireless-
approvals
).
Type
Properties
Article number
IWLAN RCoax
ANT792-4DN
RCoax helical antenna with circular
polarization for RCoax systems, 4 Bi,
2.4 GHz, IP65, N-Connector female.
6GK5792-4DN00-0AA6
ANT792-6MN
Omnidirectional antenna, mast/wall
mounting, 6 dBi 2.4 GHz, IP67, N-Connect
female
6GK5792-6MN00-0AA6
ANT792-8DN
Directional antenna, mast/wall mounting,
14 dBi 2.4 GHz, IP32, N-Connect female
6GK5792-8DN00-0AA6
ANT793-6DG
Wide angle antenna, mast/wall mounting,
9 dBi 5 GHz, IP66/67, 2 x N-Connect
female
6GK5793-6DG00-0AA0
ANT793-8DJ
Directional antenna, mast/wall mounting,
18 dBi 5 GHz, IP67, 2 x N-Connect female
6GK5793-8DJ00-0AA0
ANT793-8DK
Directional antenna, mast/wall mounting,
23 dBi 5 GHz, 2 x N-Connect female
6GK5793-8DK00-0AA0
ANT793-8DL
Directional antenna vertical-horizontal
polarized, 5 GHz, 14dBi, IP66, 2 x N-
Connector female
6GK5793-8DL00-0AA0
ANT793-8DP
Directional antenna, mast/wall mounting,
13 / 13.5 dBi 4.9 GHz and 5 GHz, N-
Connect female
This antenna is not available in Korea
6GK5793-8DP00-0AA0
IWLAN RCoax
ANT793-4MN
RCoax λ4 antenna with vertical
polarization for RCoax systems, 6 dBi,
5 GHz, IP65, N-Connector female
6GK5793-4MN00-0AA6
