2.8 Power over Ethernet (PoE)
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
38 Configuration Manual, 08/2018, C79000-G8976-C267-13
A Siemens power insert can also be used as the interface for the power input. Since a power
insert supports a power supply of 24 VDC, it does not conform with 802.3af or IEEE 802.3at.
The following restrictions relating to the use of power inserts should be noted:
WARNING
Operate the power insert only when the following conditions apply:
• with extra low voltages SELV, PELV complying with IEC 60364-4-41
• in USA/CAN with power supplies complying with NEC class 2
• in USA/CAN, the cabling must meet the requirements of NEC/CEC
• Power load maximum 0.5 A.
Cable lengths
Table 2- 1 Permitted cable lengths (copper cable - Fast Ethernet)
Cable type
Accessory (plug, outlet,
TP cord)
Permitted cable length
IE TP torsion cable with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 45 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180
0 to 55 m
IE FC TP Marine Cable
IE FC TP Trailing Cable
IE FC TP Flexible Cable
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 75 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180
0 to 85 m
IE FC TP standard cable with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 90 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180 0 to 100 m
Table 2- 2 Permitted cable lengths (copper cable - gigabit Ethernet)
Cable type
Accessory (plug, outlet,
TP cord)
Permitted cable length
IE FC standard cable, 4×2, 24
AWG
with IE FC RJ-45 Plug 180, 4x2 0 to 90 m
IE FC flexible cable, 4×2, 24
AWG
with IE FC RJ-45 Plug 180, 4x2 0 to 60 m
IE FC standard cable, 4×2, 22
AWG
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 100 m
+ 10 m TP cord
